Material “S”® group in XXL-sizes

From now on Murtfeldt offers its Material "S"® group - materials consisting of modified ultra-high molecular weight PE types (UHMW-PE) - also in sheet sizes of 6000 x 2500 mm. In addition to the established Original Material "S"® green®/natural and black, particularly Original Material "S" plus+® ESD, Original Material "S" plus+® GB, Material "S"® 1000 and all other coloured Original Material "S"® types complement the new delivery programme. The thicknesses range from 8 - 80 mm.

The new "XXL"-sizes are not only tailored for the American or Australian market but are also highly demanded in Europe thanks to their length. Companies demanding for example 6 m long profiles or guide rails for their machines will benefit from the new possibilities. Murtfeldt now offers one-piece components machined from a pressed sheet. These new sheet sizes are available from stock or at short notice, as are the established sizes.

Not only final products like curves or other large-sized finished parts, rings or format sets, but also pre-cuts can ideally be produced from the new sizes. They allow customers greater flexibility for the production of pre-cuts while reducing off-cuts at the same time - such as Murtfeldt can.
The fully automated panel-sizing saw offers these new possibilities for an optimized production of pre-cuts, so that also sizes of 6000 x 1250 mm, 3000 x 1250 mm or 1000 x 2500 mm can be offered.

Another newly installed planing system enables to plane widths up to 2700 mm and lengths of 6000 mm. Consequently, large-sized planed sheets can be used for further machining.

It will bring further advantages for the paper industry which requires Original Materials "S" plus+® GB in "XXL"-sizes. The glass-filled material with a smooth gliding and at the same time hard surface has successfully proven itself in very abrasive surroundings. In the lining sector, bunkers, silos etc. can be lined appropriately and butt welds can be reduced when using sheets in bigger dimensions. The fully automated production including planing and cutting facilities guarantees consistently high qualities.

Although almost all countries in the world refer to the metric system, inch based sheet sizes are still very popular in USA, Australia and numerous Asian countries. Standards are not 2 x 1 m or 3 x 1 m but 4 x 10 ft or 8 x 20 ft.

Material “S”® group PE types (UHMW-PE) in XXL sheet sizes of 6000 x 2500 mm


Sheet dimensions

Plastics

Thickness

Width

Length

Thickness tolerance

Original Material ”S”® green 2/3/4/5/6 1000 2000 +0/+0,8
Semi-finished product according to ISO 15527 sheet group 1.2 8 – 200 1000 2000 +0/+0,6
  2/3/4/5/6 1220 3000 +0/+0,8
  8 – 120 1000 3000 +0/+0,6
  8 – 120 1000 4000 +0/+0,6
  8 – 120 1335 2000 +0/+0,6
   NEW!  on request 8 – 100 1000 2500 +0/+0,6
  8 – 100 1250 3000 +0/+0,6
  8 – 100 1250 6000 +0/+0,6
  8 – 100 2500 6000 +0/+0,6
Original Material ”S”® natural 1/2/3/4/5/6 1000 2000 +0/+0,8
Semi-finished product according to ISO 15527 sheet group 1.2 8 – 200 1000 2000 +0/+0,6
  2/3/4/5 1220 3000 +0/+0,8
  10 – 120 1000 3000 +0/+0,6
  8 – 120 1000 4000 +0/+0,6
   NEW!  on request 8 – 100 1000 2500 +0/+0,6
  8 – 100 1250 3000 +0/+0,6
  8 – 100 1250 6000 +0/+0,6
  8 – 100 2500 6000 +0/+0,6
Original Material ”S”® black antistatic 1/2/3/4/5/6 1000 2000 +0/+0,8
Semi-finished product according to ISO 15527 sheet group 1.2 8 – 200 1000 2000 +0/+0,6
  2/3/4/5/6 1220 3000 +0/+0,8
  8 – 120 1000 3000 +0/+0,6
  8 – 120 1000 4000 +0/+0,6
  8 – 120 1335 2000 +0/+0,6
   NEW!  on request 8 – 100 1000 2500 +0/+0,6
  8 – 100 1250 3000 +0/+0,6
  8 – 100 1250 6000 +0/+0,6
  8 – 100 2500 6000 +0/+0,6
Original Material ”S”® coloured* 8 – 100 1000 2500 +0/+0,6
   NEW!  on request 8 – 100 1250 3000 +0/+0,6
  8 – 100 1250 6000 +0/+0,6
  8 – 100 2500 6000 +0/+0,6
Material ”S”® 1000 green 3/4/5/6 1000 2000 +0/+0,8
  8 – 200 1000 2000 +0/+0,6
  3/4/5/6 1220 3000 +0/+0,8
  8 – 100 1000 3000 +0/+0,6
  10 – 120 1335 2000 +0/+0,6
  10 – 120 1000 4000 +0/+0,6
   NEW!  on request 8 – 100 1000 2500 +0/+0,6
  8 – 100 1250 3000 +0/+0,6
  8 – 100 1250 6000 +0/+0,6
  8 – 100 2500 6000 +0/+0,6
Material ”S”® 1000 black antistatic 2– 6 1000 2000 +0/+0,8
  8 – 200 1000 2000 +0/+0,6
  3/4/5/6 1220 3000 +0/+0,8
  8 – 100 1000 3000 +0/+0,6
  10 – 100 1335 2000 +0/+0,6
  10 – 120 1000 4000 +0/+0,6
   NEW!  on request 8 – 100 1000 2500 +0/+0,6
8 – 100 1250 3000 +0/+0,6
8 – 100 1250 6000 +0/+0,6
  8 – 100 2500 6000 +0/+0,6

Most of these sheets are available from stock. Should any of these materials not be in stock, we will of 150 course be able to supply them at short notice. Please contact us, we will be pleased to assist you!

*Original Material ”S”® coloured: Please ask the Murtfeldt sales team for concrete sheet dimensions.



Plastics

Thickness

Width

Length

Thickness tolerance

Muralen® green Not standard warehouse stock, available on request
Muralen® natural 2 – 100 1000 2000 as per DIN EN 14632
Muralen® black antistatic 8 – 100 1000 2000 +0/+0,6
Muralen® coloured Not standard warehouse stock, available on request. Ex-stock in blue RAL5017/10, 20,30, 40 mm
Muralen® plus+AB 8 – 110 1000 2000 +0/+0,6
Original Material ”S”plus+® ESD 8 – 110 1000 2000 +0/+0,6
   NEW!  on request 8 – 100 1000 2500 +0/+0,6
  8 – 100 1250 3000 +0/+0,6
  8 – 100 1250 6000 +0/+0,6
  8 – 100 2500 6000 +0/+0,6
Original Material ”S”plus+® Bright ESD 8 – 110 1000 2000 +0/+0,6
Original Material ”S”plus+® LF 8 – 120 1000 2000 +0/+0,6
Original Material ”S”plus+® LF ESD 8 – 100 1000 2000 +0/+0,6
Original Material ”S”plus+® LFP ESD 8 – 40 1000 2000 +0/+0,6
Material ”S”8000® 8 – 130 1000 2000 +0/+0,6
Original Material ”S”plus+® AB 8 – 110 1000 2000 +0/+0,6
Original Material ”S”plus+® FP [FS]® 10 – 60 1335 2000 +0/+0,6
Original Material ”S”plus+® GB 8 – 110 1000 2000 +0/+0,6
Original Material ”S”plus+® TLS 8 – 100 1000 2000 +0/+0,6


Plastics

Thickness

Width

Length

Thickness tolerance

Murlubric® 8 – 100 1000 2000 +0/+0,6
  110 – 160 1000 1000 +0/+0,6
Murlubric® blue [FS]® 10 – 100 1000 2000 as per DIN EN 15860
Murylon® 6 Cast natural/black 10 – 100 1000 2000 as per DIN EN 15860
Murdopol® 10 – 50 1000 2000 on request
Murylon® B natural 2 – 60 1000 2000 as per DIN EN 15860
  70 – 100 610 2000 as per DIN EN 15860
Murylon® B black 8 – 50 610 2000 as per DIN EN 15860
Murylon® A natural 8 – 60 610 2000 as per DIN EN 15860
Murylon® A black 10 – 50 500 2000 as per DIN EN 15860
Murylon® A GF schwarz 10 – 100 625 2000 as per DIN EN 15860
Murytal® C natur 1 – 100 1000 2000 as per DIN EN 15860
Murytal® C black 2 – 100 1000 2000 as per DIN EN 15860
Murytal® C blue [FS]® 10 – 100 1000 2000 as per DIN EN 15860
Murytal® H natural/black 10 – 50 610 2000 as per DIN EN 15860
Murytal® ESD black 10 – 60 500 2000 as per DIN EN 15860
Murylat® natural 8 – 100 610 2000 as per DIN EN 15860
Murylat® black 8 – 80 610 2000 as per DIN EN 15860
Murylat® SP 8 – 100 610 2000 as per DIN EN 15860


Plastics

Thickness

Width

Length

Thickness tolerance

Murylon® HT 10 – 40 610 2000 as per DIN EN 15860
  50 500 2000 as per DIN EN 15860
Murinyl® 10 – 80 610 2000 as per DIN EN 15860
Murflor® 3 – 50 1000 1000 as per GKV
  10 – 50 1000 2000 as per GKV
Murflor® Carbon 10 – 40 1000 2000 as per GKV
Murflor® Bronze 10 – 30 1000 2000 as per GKV
Murflor® Glass 10 – 30 1000 2000 as per GKV
Murinit® SP 8/10 525 2000 as per DIN EN 15860
  12 – 50 625 2000 as per DIN EN 15860
Murpec® 5 – 25 1000 2000 as per DIN EN 15860
  30 – 60 615 2000 as per DIN EN 15860
Murpec® SP 10 525 2000 as per DIN EN 15860
  16/20/30/40 625 2000 as per DIN EN 15860
